CATEGORIESHongming Sheng manufactures custom wall-mounted metal brackets for electrical cabinets, control boxes, sensor units, displays and communication equipment. Bracket shapes, mounting holes and finishes follow your drawings and installation requirements.
From simple L-shaped brackets to support arms with multiple mounting points, our team can review the equipment interface, wall-side fixing layout and fabrication requirements before quotation.
Email: info@hms1688.com
Examples of fabricated metal brackets. Dimensions, hole patterns and surface requirements are defined for each project.
 Bracket reference 01 |  Bracket reference 02 | |
 Bracket reference 03 |  Bracket reference 04 |
Wall-Side FixingShow mounting-hole positions, fastener dimensions and access space for installation. Include the wall or support structure and the fixing method where these are defined by the project. | Equipment-Side MountingProvide the cabinet, box or device mounting pattern. Identify contact faces, bracket orientation and any countersunk-hole requirements so the bracket can be reviewed with the mating equipment. |
Offset and Clearance
Specify the required distance from the wall and the space needed for cables, connectors, covers and installation tools.
Loading and Use
Share the equipment weight, load position and operating environment, together with the approved design and any required validation criteria.
| Materials | Stainless steel, galvanized steel and aluminum. Specify the grade and thickness required by the design. |
|---|---|
| Shape and Profile | L-shaped brackets, custom support arms and multi-hole mounting structures according to the drawing. |
| Hole Features | Custom hole spacing, mounting patterns and countersunk holes where specified. |
| Surface Finish | Powder coating, zinc plating and anodizing for suitable aluminum parts. Finish requirements are reviewed with the material and application. |
| Supply Format | Individual fabricated brackets or pre-assembled sets according to the agreed scope. Confirm whether mounting hardware is included. |
Dimensional review focuses on the specified hole locations, bend angles, mounting faces and assembly fit. Edge condition and surface appearance are checked against the agreed requirements.
For samples, check the bracket with the actual equipment and installation layout before confirming the production revision. Repeat orders follow the approved drawings, finish and packing specification.
Send a drawing, dimensioned sketch or reference sample with the material, thickness, quantity and finish. Include both mounting patterns, required offset, equipment weight and installation environment.
Our team can review the fabrication scope, inspection requirements, packing and target delivery date before quotation.
Email: info@hms1688.com
Confidential OEM projects: Customer drawings, samples and technical information are handled confidentially. NDA support is available for custom bracket manufacturing.
Contact us and just send us your drawing (SolidWorks,ProE,CAD,PDF,DXF...)
